fix(xlsx): clip page fills one sheet point inside the top and left gridlines

[developer0hye]

File submission policy

Before attaching or committing files, read the submission policy.
Complete a security review and obtain your organization's internal approval for
public sharing where applicable. You are responsible for lawful disclosure;
the project and maintainers disclaim related liability to the extent permitted
by applicable law.

• Any submitted sample files or attachments satisfy the submission policy, or none are submitted.

Summary

Excel clips every printed page's cell fills to that page's grid region inset by one sheet point on the top and left edges, while the bottom and right edges keep the one-point positive-axis bleed and every later row and column keeps its raw origin. The converter painted the first row and first column from the raw gridline, so the rose title of the reported workbook started at x=50/y=54 where native shows x=51/y=55.

The rule was read off three native Excel 16.112 exports of the public #982 workbook rather than argued from one page: the unscaled first sheet without a print area clips its fills to [51, 55, 474, 418] around a raw title rectangle of [50, 54, 474, 145]; the fitted 0.82 sheet with the explicit A1:R12 print area clips at [55.76, 54.12] for a grid origin of [54.94, 53.30] (one scaled sheet point); and that sheet's unscaled export (#1598) clips its continuation page at x=473 for a raw fill that starts at x=472, so the clip is per page, not per sheet. Cell text is unaffected because Excel already seats content inside [B+1, B_next].

Key changes:

• excel_fill_paint.rs: a tracked fill whose track starts on the table's grid origin loses one sheet point (1 × print scale) on that edge — position moves in and the size shrinks — beside the existing bleed extension; interior fills, fills behind an unfilled gutter row or column, the bleed and the row-first paint order (XLSX: cell fill extensions overpaint neighboring colors #1599) are untouched. The origin is the table's start tag in the frame that holds the fills, because Typst inlines a single-item frame into its parent and a one-cell table's fill then carries page coordinates.
• typst_gen_table_border_tests.rs: page_fills_lose_one_sheet_point_on_the_top_and_left_grid_edges pins the rule at scale 1.0 and 0.82 on one page and on a second sheet page (the parser's continuation page), asserting the inset first row/column, the unchanged interior origins and the surviving bleed. Three existing fill tests derived the grid origin from the first cell's fill and now subtract the clip; the one-cell Excel/Word/centred-stroke comparison asserts the Excel fill starts one point inside the shared origin and reaches one point past its right boundary.
• assets/bugfixes/issue-1605/: fix-mode evidence (gt/before/after at 300 DPI, layout-audit.json, strict render-clusters-page-1.json).

The layout harness could not see this defect before the fix: matching raw rectangles skip the visible-coverage check, so native's clipped fill against our unclipped one reported geometry 0. Filed as #1742.

Related issue

Fixes #1605
Related: #1742, #1659

Testing

• cargo test --locked -p office2pdf --lib page_fills_lose_one_sheet_point — fails on main (first column/row fills start at the grid origin at both scales, on both pages) and passes with the change.
• cargo test --locked -p office2pdf --lib border_tests — 44 passed.
• cargo test --locked --workspace — 3721 passed, 0 failed.
• cargo +1.97 clippy --locked --workspace --all-targets -- -D warnings and cargo fmt --all -- --check clean.
• Native GT: the Excel 16.112 whole-workbook export recorded in XLSX: centered text shifts left on unscaled worksheet print tiles #1600 (SHA-256 2aa03caf…); before binary is main at 4919bfc; both conversions with --font-path for the Office cloud-font cache and Excel's DFonts bundle.
• mutool draw -F trace on page 1: after the fix the rose title paints [51, 55, 474, 145] (native [51, 55, 474, 145] visible under its clip; before [50, 54, 474, 145]), the pale body starts at y=144 under it as native does. Page 2 is pixel-identical before and after (magick compare -metric AE 0 at 150 DPI, identical trace rectangles), because its first filled cells sit inside gutter rows and columns.
• python3 scripts/compare_layout.py GT.pdf after.pdf --page 1 --noise-floor 0.5 --audit --fine-shift 0.5 --json; python3 scripts/compare_render.py GT.pdf after.pdf --page 1 --dpi 300 --fine-shift 0.5 --artifacts-dir … --cluster-report … --cluster-dispositions … --strict-clusters (71/71 clusters dispositioned, strict PASS); python3 scripts/compare_text_layer.py GT.pdf after.pdf --page 1 (text layer intact).

Visual impact

• No rendered PDF change
• Rendered PDF change or visual evidence added
• Reason: N/A

Visual audit

• Issue: XLSX: worksheet fills extend beyond the native used-range clip #1605
• Fixture: tests/fixtures/xlsx/issue_1603_gift_budget.xlsx (public Gift Budget and Tracker1.xlsx from Gift Budget and Tracker1.xlsx misc issues #982, SHA-256 25f5dc75dab19ea12042979a61842314ddc226e3e45d447e36b2a2a104112613)
• Page(s): 1
• Renderer and DPI: pdftoppm, 300 DPI
• Evidence mode: fix
• Layout audit report: assets/bugfixes/issue-1605/layout-audit.json
• Render cluster reports: assets/bugfixes/issue-1605/render-clusters-page-1.json
• Reference exporter differences: None
• Fine-detail threshold: 0.5pt
• Layout audit page count: Pass
• Layout audit text flow: Pass
• Layout audit visible fills: Pass
• Layout audit rectangle geometry: Pass
• Layout audit large shifts: Pass
• Layout audit fine shifts: Pass
• New follow-up issues found in this audit: None
• Model vision findings: Inspected the full native and output page 1 side by side, the 300 DPI 5% diff page, the 400x300px title-corner crops of GT/before/after, the title TEM|PLATE crop and matched 480x70px crops at the start and end of the long body line Enter in table the names…. In the corner crops the before panel's rose fill begins four device pixels (one point) above and left of native on both edges; the after panel's fill edge coincides with native on both edges, and the diff page shows no line along the panel's top or left boundary while the panel's bottom seam against the pale body is also clean (XLSX: cell fill extensions overpaint neighboring colors #1599 fixed earlier). Every remaining diff cluster is glyph-sized: the body lines match at their start and drift right by about 0.8pt by the end of the line (whole-point glyph advances, XLSX: Excel for Mac advances each sheet glyph a whole point, so long strings drift up to 1.3pt from our fractional advances #1659), the title's M shows the same drift on its diagonals, and the 8pt footer shows outline-only differences. Note: keeps its bold weight and every other run is regular; no italic, underline, hairline or border exists on this page in either render, and no cluster touches the fill edges.
